FANUC A06B-6102-H226#H520 放大器模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
FANUC A06B-6102-H226#H520 是一款 伺服放大器模塊，通常用于 FANUC CNC 控制系統中，為伺服電機提供驅動能力。以下是該型號的詳細信息：
1. 產品概述
- 制造商：FANUC（發那科）
- 產品類型：伺服放大器模塊（Servo Amplifier Module）
- 型號：A06B-6102-H226#H520
- 應用領域：
- CNC 數控機床
- 自動化生產線
- 機器人控制系統
- 其他需要精密運動控制的工業應用
2. 主要技術參數
- 輸入電壓：通常支持 200-240V 三相 AC 供電
- 功率等級：H226 版本通常屬于 中高功率 級別，適用于較大功率伺服電機
- 兼容性：
- 兼容 FANUC 0i、16i、18i、21i 系列 CNC 控制器
- 適用于 αi 系列伺服電機
- 冷卻方式：通常為 風冷 或 強制風冷
- 控制功能：
- 提供高精度的 伺服控制
- 具備 動態響應優化 以提升加工精度
- 過流、過溫、欠壓等 故障保護機制
3. 特點和優勢
- 高效驅動能力：可提供精準的扭矩控制，實現高響應的運動控制
- FANUC 可靠性：FANUC 伺服系統以高穩定性和長壽命著稱，適合高強度工業應用
- 模塊化設計：便于更換和維護，支持 FANUC 機床系統的升級
- 智能診斷功能：支持 CNC 系統的 報警和故障檢測，方便維護和排除故障
英文資料：
FANUC A06B-6102-H226 # H520 is a servo amplifier module commonly used in FANUC CNC control systems to provide drive capability for servo motors. The following is the detailed information of this model:
1. Product Overview
Manufacturer: FANUC
Product type: Servo Amplifier Module
model: A06B-6102-H226#H520
Application areas:
CNC machine tool
automatic production line
Robot control system
Other industrial applications that require precise motion control
2. Main technical parameters
Input voltage: usually supports 200-240V three-phase AC power supply
Power level: H226 version usually belongs to the medium to high power level and is suitable for high-power servo motors
compatibility:
Compatible with FANUC 0i, 16i, 18i, 21i series CNC controllers
Suitable for α i series servo motors
Cooling method: usually air-cooled or forced air-cooled
Control function:
Provide high-precision servo control
Equipped with dynamic response optimization to improve machining accuracy
Overcurrent, over temperature, under voltage and other fault protection mechanisms
3. Characteristics and advantages
Efficient driving capability: can provide precise torque control and achieve high response motion control
FANUC Reliability: FANUC servo systems are known for their high stability and long lifespan, making them suitable for high-intensity industrial applications
Modular design: easy to replace and maintain, supports upgrading FANUC machine tool systems
Intelligent diagnostic function: supports CNC system alarm and fault detection, facilitating maintenance and troubleshooting
2.產 品 展 示
