HIEE451116RW01輸出卡件
該模塊的命令反饋數據。配置非零長度后，默認為下一個可用%AI地址。PACSystems*RX3i系統手冊第12節GFK-2314T 2019年9月模擬輸出模塊473輸出命令反饋長度0用于此模塊命令反饋數據的字?jǐn)?shù)。長度默認為0。它可以設置為16。診斷參考地址%Ixxxxx通道診斷狀態數據的起始地址。這默認為下一個可用的%I塊。診斷參考長度0只讀。通道診斷數據所需的位參考位數。默認值為0，這意味著禁用通道診斷映射。將其更改為非零值以啟用通道診斷映射。模塊IC695ALG808的最大長度為256位。模塊狀態參考地址%Ixxxxx此模塊狀態數據的起始地址。這默認為下一個可用的%I塊。模塊狀態參考長度0只讀。模塊狀態數據所需的位數（0或32）。默認值為0，這意味著模塊狀態數據的映射被禁用。將其更改為非零值以啟用模塊狀態數據映射。10.4.5.1.1模擬輸出命令反饋模塊將從CPU接收的模擬輸出數據的副本返回到其相應的通道模擬輸入共享存儲器中?？梢员O(jiān)控輸出反饋，以檢查發送到通道的值。數據采用與每個通道的輸出數據相同的縮放格式。在正常操作期間，該反饋數據應與模塊輸入的一次或多次PLC掃描后的實際輸出數據相匹配。在故障、斜坡、超范圍和箝位條件下，模擬輸出數據可能與命令輸出不同。10.4.5.1.2過高溫度如果啟用了過高溫度，如果該模塊的內部溫度對于同時打開的輸出數量而言過高，則模塊會生成過高溫度警報。除了超溫故障報告和中斷的可配置選項外，超溫狀態也由該模塊狀態參考數據中的超溫位指示。始終啟用過熱狀態位的檢測。PACSystems*RX3i系統手冊第12節GFK-2314T 2019年9月模擬輸出模塊474模塊參數（續）參數默認說明I/O掃描集1將模塊I/O狀態數據分配給CPU配置中定義的掃描集。確定RX3i在未啟用/禁用端子塊的情況下輪詢數據通道故障的頻率：控制端子塊移除后是否會生成通道故障和配置的報警響應。默認設置為Disabled（禁用）意味著移除接線板時，通道故障和報警被抑制。此參數不影響模塊故障，包括啟用的接線板丟失/添加故障損壞報告，此參數控制現場斷電模塊故障的中斷。過熱啟用禁用啟用
command feedback data of this module. This defaults to the next available %AI address after a non-zero length is configured. PACSystems* RX3i System Manual Section 12 GFK-2314T Sept. 2019 Analog Output Modules 473 Output Command Feedback Length 0 The number of words used for the command feedback data of this module. Length defaults to 0. It can be set to 16. Diagnostic Reference Address %Ixxxxx Starting address for the channel diagnostics status data. This defaults to the next available %I block. Diagnostic Reference Length 0 Read Only. The number of bit reference bits required for the Channel Diagnostics data. Default is 0, which means mapping of Channel Diagnostics is disabled. Change this to a non-zero value to enable Channel Diagnostics mapping. Maximum length is 256 bits for module IC695ALG808. Module Status Reference Address %Ixxxxx Starting address for the status data of this module. This defaults to the next available %I block. Module Status Reference Length 0 Read Only. The number of bits (0 or 32) required for the Module Status data. Default is 0, which means mapping of Module Status data is disabled. Change this to a non-zero value to enable Module Status data mapping. 10.4.5.1.1 Analog Output Commanded Feedback The module returns a copy of the analog output data received from the CPU in its corresponding channel analog input shared memory. Output Feedback can be monitored to check the values being sent to the channels. The data is in the same scaled format as the output data for each channel. During normal operation, this feedback data should match the actual output data after one or more PLC scans of module inputs. During faults, ramping, over-range, and clamping conditions, the analog output data may differ from the commanded output. 10.4.5.1.2 Over-Temperature If Over-Temperature is enabled, the module generates an Over-Temperature alarm if the internal temperature of this module is too great for the number of outputs that are on at the same time. In addition to the configurable options for Over-Temperature fault reporting and interrupts, an over temperature condition is also indicated by the Over-Temperature bit in the Status Reference data of this module. Detection of the Over-Temperature status bit is always enabled. PACSystems* RX3i System Manual Section 12 GFK-2314T Sept. 2019 Analog Output Modules 474 Module Parameters (Continued) Parameter Default Description I/O Scan Set 1 Assigns the module I/O status data to a scan set defined in the CPU configuration. Determines how often the RX3i polls the data Channel Faults w/o Terminal Block Disabled Enabled / Disabled: Controls whether channel faults and configured alarm responses will be generated after a Terminal Block removal. The default setting of Disabled means channel faults and alarms are suppressed when the Terminal Block is removed. This parameter does not affect module faults including the Terminal Block loss/add fault rrupt Reporting enabled, this parameter controls interrupts for Field Power Removed module faults. Over Temp Enabled Disabled Enabled
