一拖一手動旁路柜是由三個高壓隔離開關QS1、QS2、QS3組成。手動旁路柜嚴格按照“五防”聯鎖要求設計，變頻器輸出QS2和旁路高壓隔離開關QS3機械閉鎖，完全能夠保證變頻調速系統安全運行。
1)在變頻運行狀況下，QS1、QS2閉合，QS3斷開。
如需手動切換至工頻運行時，系統先停止變頻器輸出，斷開用戶開關，再由機械操作依次斷開QS1、QS2，然后機械操作閉合QS3，使電機切換至工頻側，再合上用戶開關，使電機工頻運行；
2)在工頻旁路運行狀況下，QS3閉合，QS1、QS2斷開。
如需手動切換至變頻運行時，系統先斷開用戶開關，由機械操作斷開QS3，然后由機械操作依次閉合QS2、QS1，使電機切換至變頻側，再合上用戶開關。
2. 控制系統方案
為了更方便的操作，變頻器的起停在機旁箱進行控制，在DCS上進行監控。頻率調節通過前級的傳感器返回的電流模擬量信號（4—20mA）進行PID控制。其具體控制信號如下：
2.1 與高壓開關柜聯鎖信號
1）合閘允許：常開接點，閉合有效，此信號串聯在供電高壓開關柜的合閘回路中，當變頻器自檢完成或系統處于工頻狀態時，信號閉合，允許用戶合高壓電；
2）高壓跳閘：常閉接點，斷開有效，此信號并聯在供電高壓開關柜的分閘回路上，當變頻器發生重大故障或急停信號有效時，分?jǐn)嘤脩舾邏弘姡?/p>
2.2 變頻器DO信號
以上輸出信號全部為獨立無源干接點，默認為常開接點，閉合有效，容量大小為250V AC 5A。
2.3 變頻器DI信號
以上輸入信號僅需客戶提供獨立無源干接點，脈沖信號，除急停外，其它信號均默認為常開接點，閉合有效；
2.4 變頻器AI信號
2.5 變頻器AO信號
四、現場實際運行照片
現場變頻器運行照片
現場電機照片
五、 改造后的效果：
1. 變頻調速的節能 steps
(1) Set the parameters and check whether the packaging film is installed and whether the color code photoelectric is intact.
(2) Press the manual button to test whether the packing bag is intact.
(3) Press the automatic button to randomly sample and measure whether it meets the requirements.
2.2 equipment process flow
According to the production requirements, the process is shown in Figure 2.1
3. Scheme determination
The program flow of pillow packaging machine looks very simple, but the internal calculation is very complicated. Now most domestic businesses in the industry are still using some single chip microcomputer or some low-cost PLC (Panasonic). Due to the increasingly fierce demand and competition of some foreign customers, they also began to upgrade the equipment function and brand. Siemens PLC entered the industry under this environment, At the beginning of the design, due to the consideration of price, Siemens S7-200 series PLC was selected at the initial stage. In the final debugging stage, it was found that the scanning cycle of PLC was more than 5 times larger than Panasonic PLC. Due to the use of the
