BENTLY 3701/55-01-01繼電器輸出模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Bently Nevada 3701/55-01-01 繼電器輸出模塊是 ADAPT（ESD）緊急停機設備 的關鍵組成部分。該設備旨在對旋轉機械（如蒸汽、燃?xì)夂退啓C(jī)）進行緊急停機保護。
主要功能：
- 緊急停機保護： 在檢測到異常情況時，迅速切斷設備電源，防止損壞。
- 集成超速檢測： 內置超速檢測功能，確保設備在安全轉速范圍內運行。
- 可編程邏輯控制： 提供圖形化編程界面，用戶可根據需求設置邏輯控制。
- 冗余設計： 采用三重冗余處理器和繼電器模塊，確保系統的高可靠性和穩定性。
輸出模塊特點：
- 繼電器配置： 每個模塊配備五個繼電器，其中四個用于系統邏輯報警，剩余一個用于反映保護路徑的狀態。
- 可編程性： 繼電器的配置靈活，可根據具體應用需求進行編程設置。
總的來說，3701/55-01-01 繼電器輸出模塊通過其高可靠性和靈活性，確保了關鍵設備在緊急情況下的安全停機，防止?jié)撛趽p害。
英文資料：
The Bently Nevada 3701/55-01-01 relay output module is a critical component of the ADAPT (ESD) emergency shutdown equipment. This device is designed to provide emergency shutdown protection for rotating machinery such as steam, gas, and water turbines.
Main functions:
Emergency stop protection: When an abnormal situation is detected, quickly cut off the power supply of the equipment to prevent damage.
Integrated overspeed detection: Built in overspeed detection function ensures that the device operates within a safe speed range.
Programmable Logic Control: Provides a graphical programming interface, allowing users to set logic controls according to their needs.
Redundant design: Adopting triple redundant processors and relay modules to ensure high reliability and stability of the system.
Characteristics of output module:
Relay configuration: Each module is equipped with five relays, four of which are used for system logic alarms and the remaining one is used to reflect the status of the protection path.
Programmable: The configuration of relays is flexible and can be programmed according to specific application requirements.
Overall, the 3701/55-01-01 relay output module ensures safe shutdown of critical equipment in emergency situations and prevents potential damage through its high reliability and flexibility.
2.產 品 展 示
