Yokogawa WT1803E精密功率分析儀 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Yokogawa WT1803E 精密功率分析儀 是一款高精度的電力測量工具，廣泛應用于工業和研發領域，尤其在電氣設備、能源管理系統、以及各種需要高精度功率和電能測量的環境中。WT1803E 提供了非常高的測量精度和功能，適用于從單相到三相的各種電力系統。
主要特點：
高精度測量：
- 0.1% 基本精度，能夠提供高精度的功率和電量測量，確保在各種測試條件下的可靠性。
- 能夠準確測量各種電壓和電流信號，適應復雜的應用場景。
寬廣的測量范圍：
- 支持廣泛的電壓和電流范圍，適用于從低功率到高功率的電力設備的測試。
- 測量電壓范圍從 1 mV 到 1000 V，電流范圍從 1 μA 到 30 A，滿足多種電氣設備的需求。
三相功率測量：
- 支持 三相 系統的功率測量，能夠同時測量三相功率、功率因數、負載等關鍵參數，適用于工業設備的電力監測。
高頻響應：
- 2 MHz 的頻率響應能力，使得 WT1803E 可以進行快速響應測量，特別適合于高頻電子產品、逆變器以及其他變頻設備的電力測量。
數據記錄與分析功能：
- 內置存儲功能，支持長時間的測量數據記錄，便于分析和后期處理。
- 提供 波形圖 和 趨勢圖，使用戶能夠直觀地分析電力質量和測量數據。
全面的電力質量分析：
- 除了基礎的功率測量外，還支持 諧波分析、電能分析、功率因數、頻率分析 等電力質量的測量，幫助用戶進行綜合電力系統監控。
多種顯示與接口：
- 提供 彩色顯示屏 和 觸摸屏操作，用戶可以快速設置、調整和查看測量結果。
- 支持 USB、LAN、GPIB 等接口，方便數據導出、遠程控制和與其他設備的集成。
靈活的測量模式：
- 支持多種測量模式，包括 瞬時功率、平均功率、最大/最小功率、相對功率 等，適用于不同的應用場景。
英文資料：
Yokogawa WT1803E Precision Power Analyzer is a high-precision power measurement tool widely used in industrial and research and development fields, especially in electrical equipment, energy management systems, and various environments that require high-precision power and energy measurement. WT1803E provides very high measurement accuracy and functionality, suitable for various power systems ranging from single-phase to three-phase.
Main features:
High precision measurement:
0.1% basic accuracy, capable of providing high-precision power and electricity measurement, ensuring reliability under various testing conditions.
Capable of accurately measuring various voltage and current signals, suitable for complex application scenarios.
Wide measurement range:
Supports a wide range of voltage and current, suitable for testing power equipment from low power to high power.
The measurement voltage range is from 1 mV to 1000 V, and the current range is from 1 μ A to 30 A, meeting the needs of various electrical equipment.
Three phase power measurement:
Support power measurement for three-phase systems, capable of simultaneously measuring key parameters such as three-phase power, power factor, load, etc., suitable for power monitoring of industrial equipment.
High frequency response:
The frequency response capability of 2 MHz enables WT1803E to perform fast response measurements, making it particularly suitable for power measurement of high-frequency electronic products, inverters, and other frequency conversion equipment.
Data recording and analysis function:
Built in storage function, supporting long-term measurement data recording for easy analysis and post-processing.
Provide waveform and trend charts to enable users to intuitively analyze power quality and measurement data.
Comprehensive analysis of power quality:
In addition to basic power measurement, it also supports measurement of power quality such as harmonic analysis, energy analysis, power factor, frequency analysis, etc., to assist users in comprehensive power system monitoring.
Multiple displays and interfaces:
Provide color display and touch screen operation, allowing users to quickly set, adjust, and view measurement results.
Supports interfaces such as USB, LAN, GPIB, etc., facilitating data export, remote control, and integration with other devices.
Flexible measurement mode:
Supports multiple measurement modes, including instantaneous power, average power, maximum/minimum power, relative power, etc., suitable for different application scenarios.
2.產 品 展 示
