Yokogawa AQ6370D電信光譜分析儀 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Yokogawa AQ6370D 是一款高性能的光譜分析儀，適用于光通信系統和光學器件的特性分析。該儀器提供了卓越的光學性能和多種功能，滿足各種測試需求。
主要特點：
寬波長范圍：600 至 1700 nm，覆蓋從可見光到近紅外的廣泛波長范圍。
高波長精度：±0.01 nm，確保測量結果的準確性。
高波長分辨率：0.02 nm，能夠分辨細微的光譜特征。
大動態范圍：典型值為 78 dB，適用于測量強弱信號共存的場景。
寬功率量程：+20 至 -90 dBm，適應不同強度的光信號測量。
快速測量：在 100 nm 跨度內，測量速度可達 0.2 秒，提高測試效率。
適用于單模和多模光纖：滿足不同類型光纖的測試需求。
型號版本：
AQ6370D 提供標準版和高性能版兩種型號。高性能版在波長精度和動態范圍方面具有更高的性能指標。
應用領域：
光通信系統測試：評估和優化光纖通信鏈路的性能。
光器件研發與生產：測量激光器、光放大器、濾波器等器件的光譜特性。
光傳感：分析光傳感器和光測量系統的響應特性。
英文資料：
Yokogawa AQ6370D is a high-performance spectral analyzer suitable for analyzing the characteristics of optical communication systems and optical devices. This instrument provides excellent optical performance and multiple functions to meet various testing needs.
Main features:
Wide wavelength range: 600 to 1700 nm, covering a wide range of wavelengths from visible light to near-infrared.
High wavelength accuracy: ± 0.01 nm, ensuring the accuracy of measurement results.
High wavelength resolution: 0.02 nm, capable of distinguishing subtle spectral features.
Large dynamic range: The typical value is 78 dB, suitable for measuring scenarios where strong and weak signals coexist.
Wide power range:+20 to -90 dBm, suitable for measuring optical signals of different intensities.
Fast measurement: Within a span of 100 nm, the measurement speed can reach 0.2 seconds, improving testing efficiency.
Suitable for single-mode and multi-mode optical fibers: meeting the testing needs of different types of optical fibers.
Model Version:
AQ6370D offers two models: Standard Edition and High Performance Edition. The high-performance version has higher performance indicators in wavelength accuracy and dynamic range.
Application areas:
Optical Communication System Testing: Evaluating and Optimizing the Performance of Fiber Optic Communication Links.
Research and production of optical devices: measuring the spectral characteristics of devices such as lasers, optical amplifiers, and filters.
Optical sensing: Analyze the response characteristics of optical sensors and optical measurement systems.
2.產 品 展 示
