NI PXIE-4147測量單元模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
NI PXIe-4147 是由美國國家儀器（NI）推出的一款 4 通道精密 PXI 源測量單元（SMU），專為高引腳數應用設計。該模塊具備四象限操作功能，每個通道集成了遠程（4 線）傳感，確保精確測量。
主要特點：
高通道密度：單個模塊提供 4 個獨立的 SMU 通道，適用于需要多通道同步測量的應用。
四象限操作：每個通道支持四象限運行，能夠源出和吸收電流，滿足各種測試需求。
高速采樣率：高采樣速率有助于縮短測量時間，捕獲設備的瞬態特性，實現快速的 I-V 特性分析。
SourceAdapt 技術：可調整 PXIe-4147 對任何負載的響應，以獲得最佳的穩定性和最小的瞬態特性。
確定性硬件序列：內置高速序列引擎，支持 SMU 之間或與其他儀器（如開關或高速數字測試模塊）的同步操作。
技術規格：
電壓范圍：±8 V
直流電流范圍：±3 A
電流靈敏度：100 fA
最大直流功率：24 W（源出/吸收）
PXIe-4147 適用于半導體器件測試、電子元件特性分析以及需要高精度、多通道電源和測量的其他應用。其模塊化設計使其易于集成到現有的 PXI 測試系統中，提供靈活且高效的測試解決方案。
英文資料：
NI PXIe-4147 is a 4-channel precision PXI source measurement unit (SMU) developed by National Instruments (NI) in the United States, specifically designed for high pin count applications. This module has four quadrant operation function, and each channel integrates remote (4-wire) sensing to ensure accurate measurement.
Main features:
High channel density: A single module provides 4 independent SMU channels, suitable for applications that require multi-channel synchronous measurement.
Four quadrant operation: Each channel supports four quadrant operation, which can source and absorb current to meet various testing requirements.
High sampling rate: High sampling rate helps shorten measurement time, capture transient characteristics of the device, and achieve fast I-V characteristic analysis.
SourceAdapt technology: The response of PXIe-4147 to any load can be adjusted to achieve optimal stability and minimal transient characteristics.
Deterministic hardware sequence: Built in high-speed sequence engine, supporting synchronous operation between SMUs or with other instruments such as switches or high-speed digital testing modules.
Technical specifications:
Voltage range: ± 8 V
DC current range: ± 3 A
Current sensitivity: 100 fA
Maximum DC power: 24 W (source/absorption)
PXIe-4147 is suitable for semiconductor device testing, electronic component characteristic analysis, and other applications that require high-precision, multi-channel power supply and measurement. Its modular design makes it easy to integrate into existing PXI testing systems, providing flexible and efficient testing solutions.
2.產 品 展 示
