Bently 3500/91-02-00 190782-01 通信網關模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Bently Nevada 3500/91-02-00（部件號：190782-01）是一款通信網關模塊，專為3500系列機架提供數據通信功能，支持EGD（以太網全局數據）協議。該模塊可用于將3500系統的狀態和測量數據傳輸至其他控制系統，如DCS（分布式控制系統）或SCADA系統。
主要功能：
- 協議支持： 兼容EGD V2.01和以太網UDP/IP協議，實現高效數據傳輸。
- 以太網接口： 提供10BASE-T和100BASE-TX（雙絞線）網絡連接，符合IEEE 802.3標準。
- 數據交換： 支持生產者和消費者數據交換，包括機架狀態、報警復位、報警抑制等功能。
- 系統兼容性： 可與支持EGD協議的控制系統（如GE Mark VIe）集成，實現狀態監控和數據分析。
技術參數：
- 功耗： 典型功率7.4W。
- 安裝方式：
- 主模塊占用3500機架前部一個全高插槽。
- I/O模塊安裝于機架后部對應插槽。
- 前面板指示燈：
- OK指示燈： 顯示模塊運行狀態。
- TX/RX指示燈： 指示網絡通信情況。
應用場景：
- 電力行業： 用于發電廠設備監控，提高運行效率。
- 石油天然氣： 實時監測旋轉設備健康狀況，防止設備故障。
- 工業自動化： 連接SCADA/DCS系統，實現遠程監控和數據管理。
該模塊可顯著提高系統的監測能力，適用于對高可靠性和實時性要求較高的工業環境。
英文資料：
Bently Nevada 3500/91-02-00 (part number: 190782-01) is a communication gateway module designed to provide data communication functionality for 3500 series racks, supporting EGD (Ethernet Global Data) protocol. This module can be used to transmit the status and measurement data of the 3500 system to other control systems, such as DCS (Distributed Control System) or SCADA systems.
Main functions:
Protocol support: Compatible with EGD V2.01 and Ethernet UDP/IP protocols to achieve efficient data transmission.
Ethernet interface: Provides 10BASE-T and 100BASE-TX (twisted pair) network connections, compliant with IEEE 802.3 standard.
Data exchange: Supports data exchange between producers and consumers, including rack status, alarm reset, alarm suppression, and other functions.
System compatibility: It can be integrated with control systems that support EGD protocol (such as GE Mark VIe) to achieve status monitoring and data analysis.
Technical parameters:
Power consumption: Typical power of 7.4W.
Installation method:
The main module occupies a full height slot at the front of the 3500 rack.
The I/O module is installed in the corresponding slot at the rear of the rack.
Front panel indicator light:
OK indicator light: displays the operating status of the module.
TX/RX indicator light: Indicates network communication status.
Application scenarios:
Power industry: used for monitoring power plant equipment to improve operational efficiency.
Oil and gas: Real time monitoring of the health status of rotating equipment to prevent equipment failures.
Industrial automation: Connect SCADA/DCS systems to achieve remote monitoring and data management.
This module can significantly improve the monitoring capability of the system and is suitable for industrial environments that require high reliability and real-time performance.
