A-B 1734-ACNR 網絡適配器器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Allen-Bradley 1734-ACNR 網絡適配器 是專為 ControlNet 網絡 設計的設備，它可以將 POINT I/O 模塊 連接到 ControlNet 網絡中，支持分布式 I/O 系統。
主要特點：
- 高速數據傳輸：適配器支持高速的實時數據交換，確保設備與控制系統之間的快速通訊。
- 冗余功能：它支持 網絡冗余 和 控制器冗余，提供更高的系統可靠性和容錯能力。
- 抗干擾能力：在工業環境中，適配器具備較強的抗電磁干擾（EMI）能力，保證穩定運行。
- 網絡供電：適配器能夠通過網絡獲得供電，簡化了布線和安裝工作。
技術規格：
- 電源要求：輸入電壓為 24V DC，支持寬電壓范圍 10–28.8V DC。
- 功耗：功耗為 8W，最大功率損耗為 2.8W。
- POINTBus 電流：提供最大 1000 mA 的 5V 電流，支持多個 I/O 模塊。
- 模塊容量：最多支持連接 63 個 I/O 模塊。
應用領域：
- 工業自動化：用于將 POINT I/O 模塊集成到 ControlNet 網絡中，幫助實現靈活的自動化控制。
- 過程控制：在需要高速和可靠數據傳輸?shù)倪^程控制系統中應用。
- 制造業：用于實時數據采集與控制，連接各類現場設備。
安裝與兼容性：
- 安裝方式：可以方便地通過 DIN 導軌進行安裝，符合工業標準。
- 兼容性：與 Allen-Bradley 的 POINT I/O 模塊和 ControlNet 網絡完美兼容。
Allen-Bradley 1734-ACNR 網絡適配器，憑借其冗余設計、高速數據傳輸和強抗干擾能力，是在要求高可靠性和穩定性的工業自動化環境中理想的網絡連接方案。
英文資料：
The Allen Bradley 1734-ACNR network adapter is a device designed specifically for ControlNet networks, which can connect POINT I/O modules to the network and support distributed I/O systems.
Main features:
High speed data transmission: The adapter supports high-speed real-time data exchange, ensuring fast communication between the device and the control system.
Redundancy function: It supports network redundancy and controller redundancy, providing higher system reliability and fault tolerance.
Anti interference capability: In industrial environments, adapters have strong anti electromagnetic interference (EMI) capabilities to ensure stable operation.
Network power supply: The adapter can obtain power through the network, simplifying wiring and installation work.
Technical specifications:
Power requirements: Input voltage is 24V DC, supporting a wide voltage range of 10-28.8V DC.
Power consumption: The power consumption is 8W, and the maximum power loss is 2.8W.
POINT Bus current: Provides a maximum of 1000 mA of 5V current and supports multiple I/O modules.
Module capacity: Supports up to 63 I/O modules for connection.
Application areas:
Industrial automation: used to integrate POINT I/O modules into the ControlNet network, helping to achieve flexible automation control.
Process control: applied in process control systems that require high-speed and reliable data transmission.
Manufacturing industry: used for real-time data collection and control, connecting various on-site devices.
Installation and compatibility:
Installation method: It can be easily installed through DIN rails, in compliance with industry standards.
Compatibility: Perfectly compatible with Allen Bradley's POINT I/O module and ControlNet network.
The Allen Bradley 1734-ACNR network adapter, with its redundant design, high-speed data transmission, and strong anti-interference capability, is an ideal network connection solution in industrial automation environments that require high reliability and stability.
2.產 品 展 示
