Bently 3500/64M 176449-05 壓力監測模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Bently Nevada 3500/64M 176449-05 壓力監測模塊 是通用的壓力監測模塊，專為機械設備的振動和狀態監測設計。它是 Bently Nevada 3500 系列的一部分，主要用于關鍵設備（如渦輪機、壓縮機和泵）中的壓力信號測量、監控和保護。
產品概述
- 型號：3500/64M 176449-05
- 品牌：Bently Nevada
- 功能：實時測量和監控壓力信號，提供機械設備的運行狀態數據，支持報警和保護功能。
關鍵技術參數
| 參數 | 描述 |
|---|---|
| 輸入信號 | 支持差分和單端壓力傳感器信號輸入 |
| 輸入范圍 | ±20 mA 或 ±10 V，根據配置靈活選擇 |
| 通道數量 | 支持 4 個壓力輸入通道 |
| 分辨率 | 16 位高精度模數轉換 |
| 報警功能 | 具有警告和危險報警級別，確保及時故障響應 |
| 通信接口 | 支持與 3500 系列框架通信，提供數據集成能力 |
| 配置軟件 | 使用 Bently Nevada 3500 系列系統配置工具 |
| 電源需求 | 通過 3500 框架供電 |
| 工作溫度 | -30°C 至 +65°C |
| 外形尺寸 | 符合 3500 系列模塊標準尺寸 |
| 認證標準 | 符合 API 670 和其他工業標準 |
英文資料：
The Bently Nevada 3500/64M 176449-05 pressure monitoring module is a universal pressure monitoring module designed specifically for vibration and condition monitoring of mechanical equipment. It is part of the Bently Nevada 3500 series and is primarily used for pressure signal measurement, monitoring, and protection in critical equipment such as turbines, compressors, and pumps.
Product Overview
Model: 3500/64M 176449-05
Brand: Bently Nevada
Function: Real time measurement and monitoring of pressure signals, providing operational status data of mechanical equipment, supporting alarm and protection functions.
Key technical parameters
Parameter description
Input signal supports differential and single ended pressure sensor signal input
Input range ± 20 mA or ± 10 V, flexible selection according to configuration
The number of channels supports 4 pressure input channels
Resolution 16 bit high-precision analog-to-digital conversion
The alarm function has warning and danger alarm levels to ensure timely fault response
The communication interface supports communication with the 3500 series framework and provides data integration capabilities
Configure software using Bently Nevada 3500 series system configuration tool
The power demand is supplied through the 3500 framework
Working temperature -30 ° C to+65 ° C
The external dimensions comply with the standard dimensions of the 3500 series module
Certification standards comply with API 670 and other industry standards
2.產 品 展 示
