ProSoft 5205-DFNT-PDPS 以太網網關 PDF資料
1.產 品 資 料 介 紹：
中文資料：
ProSoft 5205-DFNT-PDPS 以太網網關 是一款工業通信模塊，用于在以太網/IP 網絡和 PROFIBUS DP 從站設備之間實現協議轉換和數據交換。該模塊專為復雜工業自動化系統設計，適用于多協議環境中的集成通信。
產品概述
- 型號：5205-DFNT-PDPS
- 品牌：ProSoft Technology
- 功能：作為以太網/IP 協議與 PROFIBUS DP 從站之間的網關，支持高效、可靠的數據通信。
關鍵技術參數
| 參數 | 描述 |
|---|---|
| 以太網端口 | 支持 10/100 Mbps 全雙工/半雙工以太網 |
| 以太網協議 | 支持 DF1 協議、以太網/IP 和 Modbus TCP |
| PROFIBUS 通信 | 支持 PROFIBUS DP-V0 從站功能 |
| PROFIBUS 速率 | 9.6 kbps 到 12 Mbps |
| 支持設備數量 | 最多支持 125 個 PROFIBUS 從站設備 |
| 數據交換容量 | 最多支持 244 字節輸入和 244 字節輸出 |
| 配置方式 | 通過 ProSoft Configuration Builder 工具 |
| 電源需求 | 24 V DC，最大 3.5 W |
| 工作溫度 | 0°C 至 +60°C |
| 外形尺寸 | 13.97 x 10.16 x 4.32 cm |
| 防護等級 | IP20 |
英文資料：
ProSoft 5205-DFNT-PDPS Ethernet Gateway is an industrial communication module used for protocol conversion and data exchange between Ethernet/IP networks and PROFIBUS DP slave devices. This module is designed specifically for complex industrial automation systems and is suitable for integrated communication in multi protocol environments.
Product Overview
Model: 5205-DFNT-PDPS
Brand: ProSoft Technology
Function: As a gateway between Ethernet/IP protocol and PROFIBUS DP slave stations, it supports efficient and reliable data communication.
Key technical parameters
Parameter description
The Ethernet port supports 10/100 Mbps full duplex/half duplex Ethernet
The Ethernet protocol supports DF1 protocol, Ethernet/IP, and Modbus TCP
PROFIBUS communication supports PROFIBUS DP-V0 slave function
PROFIBUS speed range from 9.6 kbps to 12 Mbps
Supports up to 125 PROFIBUS slave devices
The data exchange capacity supports up to 244 bytes of input and 244 bytes of output
Configuration method through ProSoft Configuration Builder tool
Power requirement 24 V DC, maximum 3.5 W
Working temperature: 0 ° C to+60 ° C
Dimensions 13.97 x 10.16 x 4.32 cm
Protection level IP20
2.產 品 展 示
