NI SCXI-1140 放大器模塊
1.產 品 資 料 介 紹：
中文資料：
NI SCXI-1140 是國家儀器（National Instruments, NI）生產的一款信號放大器模塊，設計用于測量和放大傳感器信號，適用于NI的SCXI（Signal Conditioning eXtensions for Instrumentation）模塊化測量系統。以下是關于 NI SCXI-1140 放大器模塊的基本信息和特點：
基本信息
- 制造商: National Instruments (NI)
- 型號: SCXI-1140
- 產品類型: 信號放大器模塊
- 適用平臺: NI SCXI 系列模塊化測量系統
主要特點
放大器通道數:
- 4個獨立放大器通道: 提供4個獨立的放大器通道，每個通道能夠單獨配置和控制。
放大倍數和增益:
- 可編程增益: 每個通道都具有可編程的增益設置，允許用戶根據具體應用需求調整放大倍數。
信號類型:
- 模擬信號放大: 專為放大模擬傳感器信號設計，如壓力、溫度、位移等。
精確度和穩定性:
- 高精度放大: 提供高精度的信號放大功能，確保對傳感器信號的準確測量。
- 穩定性: 具備良好的溫度穩定性和抗干擾能力，適用于各種環境條件下的長時間穩定運行。
軟件支持:
- LabVIEW: 兼容NI LabVIEW軟件，提供強大的數據采集、分析和控制功能。
- SCXI驅動程序: 支持NI的SCXI模塊驅動程序，簡化配置和編程過程。
模塊化設計:
- SCXI接口: 設計用于NI SCXI模塊化測量系統，方便與其他SCXI模塊集成，構建多功能測試系統。
應用領域:
- 傳感器信號放大: 用于各種傳感器信號的放大和處理，如機械位移傳感器、壓力傳感器等。
- 工業自動化: 在工業自動化系統中用于信號調理和數據采集。
- 實驗室測量: 在實驗室環境中用于科學研究和數據分析。
總結
NI SCXI-1140 放大器模塊是一款專業的信號調理設備，適用于各種需要精確信號放大和測量的應用場景。通過其多通道、可編程增益和高精度設計，能夠滿足復雜的實時數據采集和分析需求。其與NI LabVIEW和SCXI驅動程序的無縫集成，使其成為工業自動化、實驗室測量和科學研究中的理想選擇。
英文資料
NI SCXI-1140 is a signal amplifier module produced by National Instruments (NI), designed for measuring and amplifying sensor signals, suitable for NI's SCXI (Signal Conditioning eXtensions for Instrumentation) modular measurement system. The following is the basic information and characteristics about the NI SCXI-1140 amplifier module:
Basic information
Manufacturer: National Instruments (NI)
Model: SCXI-1140
Product type: Signal amplifier module
Applicable platform: NI SCXI series modular measurement system
main features
Number of amplifier channels:
4 independent amplifier channels: Provide 4 independent amplifier channels, each channel can be configured and controlled separately.
Magnification factor and gain:
Programmable gain: Each channel has programmable gain settings, allowing users to adjust the amplification factor according to specific application requirements.
Signal type:
Analog signal amplification: designed specifically for amplifying analog sensor signals, such as pressure, temperature, displacement, etc.
Accuracy and stability:
High precision amplification: Provides high-precision signal amplification function to ensure accurate measurement of sensor signals.
Stability: It has good temperature stability and anti-interference ability, suitable for long-term stable operation under various environmental conditions.
Software support:
LabVIEW: Compatible with NI LabVIEW software, providing powerful data collection, analysis, and control functions.
SCXI driver: SCXI module driver that supports NI, simplifying configuration and programming processes.
Modular design:
SCXI interface: designed for NI SCXI modular measurement system, facilitating integration with other SCXI modules and building a multifunctional testing system.
Application field:
Sensor signal amplification: used for amplifying and processing various sensor signals, such as mechanical displacement sensors, pressure sensors, etc.
Industrial automation: Used for signal conditioning and data acquisition in industrial automation systems.
Laboratory measurement: used for scientific research and data analysis in a laboratory environment.
summary
The NI SCXI-1140 amplifier module is a professional signal conditioning device suitable for various application scenarios that require precise signal amplification and measurement. Through its multi-channel, programmable gain, and high-precision design, it can meet complex real-time data acquisition and analysis needs. Its seamless integration with NI LabVIEW and SCXI drivers makes it an ideal choice for industrial automation, laboratory measurement, and scientific research.
2.產 品 展 示
3.產 品 展 示
