Schneider 140CPS11420電源模塊
1.產 品 資 料 介 紹：
中文資料：
Schneider 140CPS11420電源模塊是一款來自施耐德電氣的Modicon Quantum PLC電源模塊。以下是關于該電源模塊的詳細信息和特點：
- 基本參數：
- 輸入電壓/電源類型：支持230V交流（170~276V）和115VAC（93~132V），頻率為47~63Hz。
- 輸出電流：根據輸入電壓的不同，輸出電流分別為750mA（230V）和1300mA（115V）。
- 瞬間峰值電流：在115V時為38A，在230V時為19A。
- 額定功率：VA值為130VA。
- 電源特性：
- 電源輸出電流：在60℃時，可求和電流為20A，獨立電流為11A。
- 功率消耗：基礎消耗為6W，并隨輸出電流的增加而增加（1.5x輸出電流）。
- 保險絲等級：采用2A慢斷型保險絲。
- 諧波失真：小于或等于10%的基本有效值。
- 認證與標準：
- 產品通過CUL認證。
- 符合RoHS標準。
- 其他信息：
- 輸出電壓：輸出1的電壓為5.1Vdc。
- 直接PLC電源模塊：設計為可疊加或獨立使用的PLC電源模塊。
- 應用范圍：廣泛應用于機床、紡織機械、印刷機械、造紙機械、塑料機械、包裝機械、食品機械、建筑機械、起重機械、暖通空調等多個行業。
- 價格與供應：
- 根據市場供應情況，價格會有所不同。多家供應商提供此電源模塊的全新原裝現貨，價格區間在數百元至數千元之間。
綜上所述，Schneider 140CPS11420電源模塊是一款功能強大、性能穩定的PLC電源模塊，適用于多種工業自動化和控制應用。
英文資料
The Schneider 140CPS11420 power module is a Modicon Quantum PLC power module from Schneider Electric. The following is detailed information and features about the power module:
Basic parameters:
Input voltage/power type: Supports 230V AC (170-276V) and 115VAC (93-132V), with a frequency of 47-63Hz.
Output current: Depending on the input voltage, the output currents are 750mA (230V) and 1300mA (115V), respectively.
Instantaneous peak current: 38A at 115V and 19A at 230V.
Rated power: The VA value is 130VA.
Power characteristics:
Power output current: At 60 ℃, the summatable current is 20A, and the independent current is 11A.
Power consumption: The basic consumption is 6W and increases with the increase of output current (1.5x output current).
Fuse rating: 2A slow break type fuse is used.
Harmonic distortion: Basic effective value less than or equal to 10%.
Certification and Standards:
The product has passed CUL certification.
Complies with RoHS standards.
Other information:
Output voltage: The voltage of output 1 is 5.1Vdc.
Direct PLC power module: Designed as a PLC power module that can be stacked or used independently.
Application scope: Widely used in multiple industries such as machine tools, textile machinery, printing machinery, papermaking machinery, plastic machinery, packaging machinery, food machinery, construction machinery, lifting machinery, HVAC, etc.
Price and Supply:
Prices may vary depending on market supply conditions. Multiple suppliers provide brand new original stock of this power module, with prices ranging from hundreds to thousands of yuan.
In summary, The Schneider 140CPS11420 power module is a powerful and stable PLC power module suitable for various industrial automation and control applications.
2.產 品 展 示
